8ft/2700mm Spindle Rotary Peeler Line:
Face veneer is an essential material for many wood panel products, including plywood, LVL, and more. Face veneer is primarily made from expensive, century-old tree species, so choosing the best spindle rotary peeler is essential for producing the best quality face veneer.
The main process of the line includes: raw log conveyor -> hydraulic debarker for rounding the wood -> hydraulic spindle rotary peeler -> CNC veneer shear -> automatic veneer stacker.
Specifications:
| Machine Name | 8-foot Rotary Log Peeler with Mechanical Spindle |
| Machine Model | BXQ1727/17JX |
| Maximum Working Diameter | Ø 1700mm |
| Maximum Working Length | 2600mm |
| Minimum Working Diameter | Ø 120mm |
| Veneer Thickness Range | 0.18 - 3.6mm |
| Peeling Knife Size | 2700 x 140 x 13mm |
| Main Spindle Speed | 87rpm/min |
| Machine Motor Power | 40kW |
| Machine Dimensions | 5500(L) x 2300(W) x 2500mm(H) |
| Machine Net Weight | 6800Kgs |
