Rotary log peeling machine with hydraulic spindles
Time: 2026-09-24 11:05
Description:
Time: 2026-09-24 11:05
Description:
Jasonqiao@sdfocusmachinery.comProduct Details
| Machine name | 8-Foot Hydraulic Spindle Rotary Log Peeling Machine |
| Machine model | BXQ1626/17 |
| Maximum working diameter | Ø1600mm |
| Minimum working diameter | Ø170mm |
| Maximum working length | 2700mm |
| Veneer thickness range | 0.35 - 4.2mm |
| Chuck diameter | Ø110mm (Small) |
| Ø200mm (Large) | |
| Chuck rotation speed | 0-200 rpm |
| Main motor power | 118kW |
| Fan motor power | 5.5kW |
| Tool chuck motor | 5.5kW |
| Chuck motor | 1.8kW |
| Tool cartridge rear angle motor | 1.1kW |
| High-pressure pump motor | 4.4kW |
| High-displacement pump motor | 7.5kW |
| Maximum hydraulic working pressure | 6kW |
| Total motor power | 145.5kW |
| Weight | 36,000kg |
| Machine overall dimensions | 10500 x 2600 x 42mm |
