Rotary veneer peeling machine with hydraulic spindle
Time: 2026-10-15 15:10
Description:
Time: 2026-10-15 15:10
Description:
Jasonqiao@sdfocusmachinery.comProduct Details
Spindle Veneer Peeling Lathe
- The spindle veneer peeling lathe is mainly used for peeling precious veneer and large-diameter logs, such as okoume, birch, beech, etc.
- The minimum peeling thickness can reach 0.1 mm, and the maximum log peeling diameter is 1500 mm. Its fully automatic peeling line and accurate peeling thickness are highly praised by our customers.
- We adopt Taiwan Delta automatic control system, all motors are Huali brand. The thickness adjustment can be controlled by both CNC and reducer.
- This is a reliable quality machine. Our equipment has been exported to Russia, Gabon, India, Europe and more than 30 countries.
Hydraulic Large Diameter Double Chuck Thick Core 4ft Spindle Veneer Peeling Machine
Technical Specifications
| Item | Vertical Type | Horizontal Type |
|---|---|---|
| Max. Log Diameter | 1500mm or customizable | 900mm |
| Peeling Thickness | 0.1-2.6mm | 0.1-2.6mm |
| Peeling Speed | 0-80m/min | 0-80m/min |
| Total Motor Power | 40.45KW | 40.45KW |
| Chuck Type | Double Mechanical Chuck | Double Mechanical Chuck |
| Total Weight | 8000KG | 7900KG |
| Overall Dimension | 6500mm2350mm2600mm | 6500mm2350mm2600mm |
