Position: HOME > Plywood Machinery >
Plywood Machinery
Two dust collection bags
Time: 2026-10-16 15:57
Description:
Time: 2026-10-16 15:57
Description:
Jasonqiao@sdfocusmachinery.comProduct Details
| Item | MF9022 Single Bag Dust Collector | MF9030 Double Bag Dust Collector | MF9030 Single Bag Dust Collector | MF9040 Double Bag Dust Collector | MF9055 Double Bag Dust Collector |
|---|---|---|---|---|---|
| Motor Power | 380V/220V/50HZ, 2.2KW | 380V/50HZ, 3KW | 380V/50HZ, 3KW | 380V/50HZ, 4KW | 380V/50HZ, 5.5KW |
| Air Flow | 2350m³/h | 3150m³/h | 3150m³/h | 4450m³/h | 6000m³/h |
| Air Velocity | 30–45m/sec | 30–45m/sec | 30–45m/sec | 30–45m/sec | 30–45m/sec |
| Inlet Size | 100mm × 3pcs | 100mm × 3pcs | 100mm × 3pcs | 100mm × 4pcs | 100mm × 6pcs |
| Dust Bag Spec. | 470mm × 2pcs | 470mm × 4pcs | 470mm × 2pcs | 630mm × 4pcs | 630mm × 4pcs |
| Overall Dimension | 940×530×2000mm | 1170×530×2000mm | 940×530×2000mm | 1800×700×2350mm | 1800×700×2350mm |
| Packing Size | 960×560×510mm | 1170×560×520mm | 960×560×510mm | 1460×700×700mm | 1460×700×700mm |
| Net Weight | 35kg | 49kg | 40kg | 66kg | 76kg |
| Gross Weight | 38kg | 52kg | 42kg | 70kg | 80kg |
